Core Capabilities
Precision Dimensional Tolerance
We consistently achieve ±0.005mm (IT5–IT7 grade) precision, meeting the stringent requirements of high-end electronic products.
Standard Tolerance: ±0.01mm
Precision Tolerance: ±0.005mm
Ultra-Precision Capability: ±0.002mm on critical features
Micro & Complex Structure Machining
Expert in machining miniature features and complex geometries:
Minimum Hole Diameter: Φ0.3mm
Minimum Wall Thickness: 0.3–0.5mm
Advanced 5-axis CNC machining - multi-angle features in a single setup
This reduces tolerance stack-up and improves structural integrity and assembly efficiency.
Thermal Management Performance
Specialized in precision CNC aluminum heatsinks and thermal components.
|
Material |
Thermal Conductivity (W/m·K) |
Typical Applications |
|
Aluminum 6061 |
167 |
General heatsinks |
|
Aluminum 6063 |
201 |
Optimized fin structures |
|
Copper |
401 |
High-power module bases |
Capable of machining high-aspect-ratio fins (0.3mm thickness, 30mm+ height).
Conductivity & EMI Shielding
High-performance EMI shielding enclosure solutions:
Shielding Effectiveness: 60–100 dB (frequency dependent)
Recommended Materials: Beryllium Copper, Silver-plated Aluminum, Conductive Coatings
Integrated features: shielding cavities, grounding bosses, and gasket grooves
Material Compatibility
|
Material |
Key Advantages |
Typical Applications |
|
Aluminum 6061/7075 |
Lightweight, excellent thermal conductivity |
Enclosures, heatsinks, brackets |
|
Copper / Brass |
Superior electrical & thermal conductivity |
Busbars, terminals, heat spreaders |
|
Stainless Steel |
Corrosion resistance & strength |
Medical & aerospace electronics |
|
Titanium |
Ultra-light, high strength |
Aerospace electronic structures |
|
PEEK |
High-temperature, chemical resistant, insulating |
Medical & semiconductor parts |
|
FR4 / Engineering Plastics |
Excellent electrical insulation |
PCB brackets & insulators |
Surface Finishing
|
Surface Treatment |
Main Benefits |
RoHS Compliant |
Typical Use Cases |
|
Hard Anodizing |
Wear & corrosion resistance |
Yes |
Aluminum enclosures |
|
Electroless Nickel / Nickel Plating |
Conductivity & wear resistance |
Yes |
EMI shielding parts |
|
Gold Plating |
Excellent conductivity & oxidation resistance |
Yes |
High-frequency connectors |
|
Conductive Coating |
EMI shielding |
Yes |
Shielding enclosures |
|
Bead Blasting + Passivation |
Uniform matte finish |
Yes |
Aesthetic & medical parts |
Rapid Prototyping
Standard Prototype Lead Time: 3–5 working days
Express Service: As fast as 48 hours
Professional DFM (Design for Manufacturability) analysis provided within 24 hours
Fast online quoting system to accelerate your product iteration.
Quality & Consistency
Yield Rate: ≥ 99.5%
Advanced Inspection Equipment: CMM, X-Ray, Optical Comparator, Spectrometer
Full SPC (Statistical Process Control) implementation
Complete documentation: FAI reports, full dimensional inspection, material certificates
Application Areas
5G Communication Base Station Components Precision waveguides, filter cavities, and thermal enclosures for stable high-frequency signal transmission.
Aerospace Electronic Structural Parts Lightweight, high-strength components meeting extreme reliability and weight requirements.
Medical Electronic Enclosures Biocompatible materials with cleanroom-grade surface finishes compliant with medical standards.
Industrial Control PCB Brackets & Housings High-precision mounting solutions for stable PCB positioning and heat dissipation.
Consumer Electronics Precision Parts Miniature components for smart wearables, drones, AR/VR devices, and more.
Automotive Electronics Connectors & Sensor Housings High-reliability parts for EV BMS, ADAS systems, and other automotive electronics.
FAQ
Q: What is your minimum order quantity (MOQ)?
A: No strict MOQ - we support orders from 1 piece for prototypes.
Q: What file formats do you accept?
A: STEP, IGES, STL, DXF, SolidWorks, and other standard CAD formats.
Q: Which tolerance standard do you follow?
A: Default ISO 2768-mK. Tighter tolerances (±0.005mm) are available upon request.
Q: Can you provide material and surface treatment certifications?
A: Yes, full Material COC, RoHS/REACH reports, and plating thickness certificates are available.
Q: What is your typical prototype lead time?
A: 3–5 working days for standard projects. Faster options available for urgent needs.
Q: Do you sign NDA agreements?
A: Yes. We strictly protect customer intellectual property and can sign NDA before project discussion.
Q: What are your accepted payment terms?
A: T/T, wire transfer, and PayPal for samples. Flexible terms for bulk orders.
Q: How do you ensure EMI shielding performance?
A: Through optimized shielding design and conductive surface treatments. Test data and reports can be provided.
Q: Do you support export compliance?
A: Yes. All products comply with international export regulations and customs requirements.
Q: Can you support IATF 16949 for automotive electronics projects?
A: Yes. We have relevant process experience for automotive-grade electronic components.
